Layout Auto Resize

Summary

The Layout Auto Resize module is a family of self-sizing layout containers (vertical, horizontal and grid) that add, remove, reorder and clear child items at runtime or in the editor, resizing their RectTransform to fit and firing events on every change.

Modules Dependencies

This module depends on UGTK LibrariesExtensions: UGTK.LibrariesExtensions.GameObjectExtension (children helpers such as GetChildren/DestroyImmediateAllChildren) and UGTK.LibrariesExtensions.AnchorLibrary (E_AnchorPosition, SetAnchor).

Setup

Choose the prefab that matches the direction the content grows in, then put your elements under it:

Prefab	Component	Arranges
`HorizontalAutoResize`	`Mn_HorizontalAutoResize`	a row
`VerticalAutoResize`	`Mn_VerticalAutoResize`	a column
`GridAutoResize`	`Mn_GridAutoResize`	a grid

Set the spacing and the S_Padding in the inspector; the children are then sized to fill the space that is left. ElementExample shows what a child looks like.

For a list longer than the screen, start from Vertical Scroll View Autoresize or its horizontal twin instead of adding a scroll view around one of the above - they are already wired, including Mn_SelectorScrollView for bringing the current element into view.

This is not Unity's layout system, and the two fight if you stack them. These components write the children's RectTransform directly, so a HorizontalLayoutGroup or a ContentSizeFitter on the same object will keep overwriting the result and produce a layout that flickers or settles somewhere neither of them intended. Use one or the other on any given object.

How To Use

Add the container that fits your layout to a UI object:
Mn_VerticalAutoResize or Mn_HorizontalAutoResize for single-axis lists.
Mn_GridAutoResize for a columns × rows grid.
Optionally assign an itemPrefab and maxItems (axis containers). Add items via AddItem(GameObject), or AddItem() to instantiate the prefab; the container reparents, positions and resizes automatically.
Manage content with RemoveItem, RemoveLastItem, RemoveItemAtIndex, ClearChildren, and (axis) MoveItemBefore/MoveItemAfter; the grid also supports AddItemAtCoordinates/RemoveItemAtCoordinates.
Read children with GetAllItems(), GetChild(index) or GetChild<T>(index), and subscribe to onItemAdded, onItemRemoved and onCleared.

Testing Scene

Open LayoutAutoResizeScene in the module's Debug/ folder.

What to do, in order:

Add and remove children and watch the container resize.
Put a very long text in one child.
Resize the parent while the scene is running.
Nest one auto-resize inside another.

Step 4 is the one that bites: two layouts each waiting for the other to settle can ping-pong for a frame or two, or never settle at all. If the layout flickers, that is what you are looking at.

LayoutAutoResizeScene: the row, the grid and the vertical list all size their children to the space available. The <- and -> buttons drive Mn_SelectorScrollView, which brings the current element into view - watch the middle panel change as the selection moves.

Technical Info

Mn_LayoutAutoResize: abstract base with the add/remove/clear API, child accessors and the item events.
Mn_AxisAutoResize: abstract single-axis base (defined in Mn_SingleAxisAutoResize.cs) adding prefab-based creation, maxItems enforcement, reordering and prefab-size preservation.
Mn_VerticalAutoResize / Mn_HorizontalAutoResize: concrete single-axis containers.
Mn_GridAutoResize: grid container handling columns/rows, cell size, spacing, padding, free-resize and auto-centering.
Mn_SelectorScrollView: helper scroll-view selector built on the layout.
S_Padding: serializable top/bottom/left/right padding struct used by the grid.
